Vapor Phase

Steel Carbon Vessels

E

Applications:  North American Aqua has many sizes of vapor phase steel carbon vessels available.  These vessels are used primarily for commercial remediation and filtration applications.



Design:  All vessels designed to 50 psi design pressure.  All models feature a stainless steel wire mesh screen suspending the carbon bed creating an unrestricted circular upward air flow thus utilizing the entire carbon bed.



G

C

K

J

F M N P

J

D

K

B

A

T S R H

E

E

J

G

C

Carbon:  4 x 10 Mesh

Exterior Finish:  Enamel Paint

Interior Finish:  Epoxy Lined



A	SIDE SHELL	J	FORK TUBES 3”x 8” x 3/16” x 36”
B	HEAD	K	LIFT LUG
C	PRESSURE GAUGE	M	GASKET 11” x 15”
D	4” FNPT EFFLUENT	N	BOLT
E	1 ½ “ PIPE PLUG	P	NUT
F	MANHOLE	R	STEEL GRATING
G	4” MNPT INFLUENT	S	STAINLESS STEEL SCREEN
H	ANGLE RING	T	SCREEN SUPPORT RING – 3 PCS.
