Vapor Phase

Carbon Steel Drums

Vapor phase carbon steel drums are an economical and versatile carbon filtration system.  Ideal for a variety of commercial projects, limited applications, temporary sites, and secondary site clean-ups, these systems are easy to install, change-out, and remove.

Applications:

Drum Volume:   55 gallon



Note:  Additional drum sizes available upon request.  Actual configurations may vary.



Drum Material:  16-gauge steel body with removable lids and a double epoxy phenolic coating over the entire inner surface.

Contact Time:  Approximately 7.5 seconds.



Dimensions:  7/16” x 35 1/16”



Carbon:  180 lbs. of 4 x 10 mesh



Design Pressure:  5 psi MAX



SCFM:  47

Vapor Phase Drum Specifications:

Influent

Effluent
