Liquid Phase Steel

Carbon Vessels

N



Dimensions	Volume	Carbon	Flow Rate	Contact time
20” X 60”	85 gal.	250 lbs	8.5 gpm	7.6 min
24” X 60”	125 gal.	400 lbs	12 gpm	8.6 min
30” X 60”	200 gal.	600 lbs	20 gpm	7.8 min
36” X 60”	300 gal.	900 lbs	30 gpm	7.8 min
42” X 72”	485 gal.	1475 lbs	50 gpm	8.0 min
48” X 72”	650 gal.	1950 lbs	65 gpm	7.9 min
54” X 72”	830 gal.	2500 lbs	80 gpm	7.9 min
60” X 72”	1040 gal.	3150 lbs	100 gpm	8.2 min
72” X 72”	1540 gal.	4650 lbs	150 gpm	7.9 min

LIQUID PHASE STEEL CARBON VESSEL  SPECIFICATIONS

Carbon:  8 x 30 Mesh

Exterior Finish:  Enamel Paint

Interior Finish:  Epoxy Lined

Design:  All vessels designed to 100 psi.   All models feature a polypropylene hub and lateral distributor/collection system creating even distribution throughout the vessel to prevent channeling.

G

FKLM

D

N

D

H

N

G

A

D

B

J

FKLM

C Air Release & Pressure Gauge

NORTH AMERICAN AQUA        ENVIRONMENTAL, LLC

ENVIRONMENTAL REMEDIATION SPECIALISTS

WATER & AIR FILTRATION SYSTEMS

Applications:  North American Aqua has many sizes of liquid phase steel carbon vessels available.  These vessels are used primarily for commercial remediation and filtration applications.
